Description
Toyota engine list
Toyota 1JZ (non VVT-i / VVT-i version)More
Toyota 2JZ (non VVT-i / VVT-i version)More
Manual gearbox (Petrol)
Lexus IS200 1G-FE Aisin AZ6 J160 (first gen.)
Gearbox adapter required
F0J160-JZ
Flywheel Type: Single Disc
Diameter of Friction Plate: 240mm / 9.45″
Recommended clutch pressure plate: Sachs 3000 950 742
Clutch disc: from Sachs clutch kit 3000 950 742
Release bearing required: Sachs 3000 950 742
Clutch fork required: Dedicated to your gearbox
Starter required (not included): Toyota JZ (OE) without additional pinion cover
Flexplate / ring gear / Drive plate required: Toyota OE 32101-30090 | 32101-22050 + one spacer OE 32116-22020 4.5mm between the engine block and the flexplate
Flywheel weight: 5.60 kg / 12.35 lb
Tightening torque for flywheel bolts: 72Nm + glue
—————-
Guides & Info
| Bilmärke | Toyota |
| Engine code | 1JZ |
| Engine code | 2JZ |
